The constant promotion of the wave of intelligent automobile electronics accelerates more and more automobile enterprises to improve the personalized intelligent driving experience of the whole vehicle by configuring or upgrading the intelligent cockpit system. The application of on-board cameras, displays, camera monitoring systems (CMS), HUD and other image systems on the automobile platform is growing rapidly.

In 2016, the ECE R46 standard was updated to allow electronic rear-view mirrors based on CMS system to replace optical exterior rear-view mirrors. The corresponding national mandatory standard and regulation GB15084 Performance and Safety Requirements for Motor Vehicle Indirect Vision Devices (Draft for Approval) has been published in the first half of 2022, or will be released and implemented soon. The image quality inspection of related products will soon become a national mandatory inspection project.

As the first intelligent driving cabin/CMS image automatic testing laboratory in South China, Guangzhou Shuntai has exclusively customized a complete set of CMS laboratory testing technical solutions, which can meet the full set of standard and regulatory testing requirements for products from the optical performance test of interior atmosphere lamps to the on-board camera monitor CMS system.

The test chart card, scattering light source, large fill light source, PLS dual light source system, I29 two-dimensional imaging luminance meter, FPD cone lens and other domestic and foreign first-class high-end equipment equipped in the laboratory can meet the requirements of domestic and foreign standards and regulations from GB 15084, QCT/1128 to ISO 16505, ECE R46, etc. The test items cover the indirect vision from Class I to Class VI completely, and can quickly and accurately analyze the output: resolution, brightness contrast, gray level Product image test and analysis results of color restoration, geometric distortion, depth of field, sharpness, etc.
